DL-LYJ-12MG350 tape casting machine takes a mixed slurry through a degassing device and supplies it to the feed box. A laser displacement sensor controls the liquid level height. Then, a scraper is used to shape the slurry into thin film blanks with a certain strength and flexibility. After passing through the drying path and nozzle, it undergoes fully automatic film alignment. The baseband, along with the green bodies, is collected for later use. Alternatively, after drying, the green bodies can be peeled, trimmed, and then cut to the width specified by the user. This system finds extensive applications in research institutes and enterprise for casting processes. Advanced servo tension control and rapid alignment correction ensure high automation throughout the entire process, from feeding to collecting the green bodies.
DL-LYJ-12MG350 tape casting machine takes a mixed slurry through a degassing device and supplies it to the feed box. A laser displacement sensor controls the liquid level height. Then, a scraper is used to shape the slurry into thin film blanks with a certain strength and flexibility. After passing through the drying path and nozzle, it undergoes fully automatic film alignment. The baseband, along with the green bodies, is collected for later use. Alternatively, after drying, the green bodies can be peeled, trimmed, and then cut to the width specified by the user. This system finds extensive applications in research institutes and enterprise for casting processes. Advanced servo tension control and rapid alignment correction ensure high automation throughout the entire process, from feeding to collecting the green bodies.
Equipment model Equipment Specifications Cutting tape material Casting width Casting speed Casting thickness Scraper height Applicable viscosity Scraper gap control
Casting thickness accuracy Baseboard temperature control
Dry area
Automatic feeding system
Liquid level height Edge trimming and slitting Electrostatic dust removal Tension control Operating Voltage Equipment power | DL-LYJ-12MG350 15500*1000*1500MM (L*W*H) PET film (50 - 188um) 350mm 0.05 - 6.0 (m/min) 10um - 1500um 5 - 4500um 300 - 50000 (mpa.s) Manually turning the knob to rotate the screw rod controls the gap, with Electronic Dial Indicator to display height. ±(1um+2%belt thickness) RT - 120℃ (±0.1℃), the max inlet air temperature is 150℃ Length 12 meters, divided into 3 areas, 12 sections of base plate with independent heating, Upper upwind heating box Fully automatic feeding, PID control flow rate and precise ±0.1mm 0.0 - 40.0mm Scissor round knife slitting Four sets The servo motor controls the tension, baseband operates without fluctuations 380V 50/60HZ 40KW |
